shutterstock 1578342493 1
gate valve

How Does Bellows Gate Valve Work

The Bellows Gate Valve was a special valve that had bellows attached to it. The bellows helped to provide a tight seal, preventing any leakage. The valve was made of cast iron and had a sturdy construction. It was installed in a section of the pipeline where the flow needed to be regulated.

Read More »
01839b2bba6537a003fe5492fc880c7 1
Globa valve

Common Problems in the Use of Bellows Globe Valves

1. One of the most common issues with Bellows Globe Valves is leakage. The bellows can sometimes wear out or become damaged over time. This can cause fluid or gas to escape through the valve. It leads to reduced efficiency and can cause potential safety hazards.

2. Additionally, Bellows Globe Valves can also experience problems with their seating surfaces. If the valve is not aligned or the seating surfaces are damaged, it can result in uneven flow or leakage. This can lead to reduced efficiency, increased maintenance costs, and potential safety hazards.

Read More »
shutterstock 531329203 1
gate valve

How Should the Bellow Gate Valves be installed?

Bellow gate valves are a type of valve used in pipelines and process systems. They control the flow of fluids or gases. Its name is due to their bellows-like structure. This provides a flexible seal that expands and contracts as the valve opens and closes. The valve consists of a gate or wedge-shaped disc that moves up and down to open and close the valve. The disc connects to a valve stem that passes through the valve’s bonnet, and an actuator operates it.

The bellows, made of metal, such as stainless steel, welded to the valve body and bonnet. They provide a flexible seal that can withstand high temperatures and pressures. And can compensate for the thermal expansion or contraction of the pipeline.

Read More »
shutterstock 1444305056 2
Y-Strainer

How Does the Y-filter Work?

The Y-Type strainer filter is Y-shaped that removes solid particles from liquid, oil, and gas. The purpose of it is to save downstream mechanical equipment from getting damaged. When liquid enters them, their filtering cartridge removes the debris, sending the clear liquid into the system.

Read More »
shutterstock 2192721161 1
Y-Strainer

What Is A Y-type Filter?

The Y-type filter is a device used in pipelines. It removes impurities from the fluid being transported. It fixes the water level or other equipment to remove impurities. This filter protects the valve at the inlet end of pressure-reducing and pressure-relief valves. The filter consists of a screen that is placed across the pipeline.

Read More »
shutterstock 2225731275 1
Valves

How Can I Tell if a Valve Is Open Or Closed?

When someone is told if a valve is open or closed, they are not interested in the valve orientation. But read more if you want to learn when the valve is open or closed or if the flow is passing through. For checking if the valve is open or closed, the basic rule is the rotation of the handle. The valve is available if the handle aligns with the flow path. Of course, this only uses manual-style valves like the ball valve. There are exceptions to this rule, such as with actuated valves operated remotely.

Read More »
shutterstock 1025749681 1 1
globe valve

How Should The Bellow Globe Valve Be Installed?

The valve installed on the pipeline must have the area for operation and maintenance. For flanged stop valves, users should select bolts according to the temperature and medium. For butt-end valve construction, cast must will weld and heat-treat to given standard requirements. Welding must be performed by skilled personnel only after process qualification. You should check the location arrow while opening and closing the valve. Overusing the “F” twist can show warping of bellows and damage to inner parts.

Read More »
shutterstock 454910143 1
butterfly valve

What Is A Butterfly Valve?

Butterfly valves are a line of quarter-turn rotational valves used to shut off flow.

In other words, a butterfly valve is a tool that regulates the flow of materials in a large pipe by rotating a disc. They are used in various techniques, media, water supply, and pumping stations. Butterfly valves have critical advantages over other valve types: lighter weights, & lower cost.

Read More »
shutterstock 705005932
globe valve

What Is The Difference Between A Globe Valve And A Throttle Valve?

The working principle of the globe valve is to close the sealing surfaces with the disc. Globe valves are directional during installation and only allow a one-way media flow. The end-to-end and face-to-face dimensions of the globe valve are more than other valves. The fluid resistance is extensive, so valve sealing is not vital for long work. The throttle valve controls fluid flow by changing the choke length or cross-section.

Read More »
